加热器

Model:	Guardian 60	Guardian 100	Guardian 250	Guardian 325
Rating
Maximum Input (Btun)	60,000	100,000	250,000	325,000
Minimum Input (variabie from)	30,000	50,000	160,000	200,000
Heater Configuration:
Hot Surface Ignition	AW060	AW100	AW250	AW325
Spark lgnition	AD060	AD100	AD250
Pilot lgnition			AB250
Fuel Consumption (max.):
Liquid Propane Gas (lbsJhr.)	2.8	4.6	11.6	15.1
Natural Gas (cu. fLhr.)	60	100	250	325
HeatedAir Oulput (CFM)	240	400	1,100	1,700
inlet Gas Supply Pressure
Liquid Propane Gas min. /max.(in. W.C.)	11.0/13.5	11.0/13.5	11.0/13.5	11.0/13.5
Naturall Gas min. I max. (in. W.C.)	7.0/13.5	7.0/13.5	7.0/13.5	7.0/13.5
Electrical Supply (Volts Hz/Phase):	115/60/1	115/60/1	115/60/1	220/60/1
Amps (Starting/Cont Oper,)
Hot Surface Ignition	7.0/1.1	7.5/1.4	11.8/4.5	8.2/2.6
Spark lgnition	2.0/1.1	4.0/1.6	11.8/4.5
Pilot Ignition			11.8/4.5
Cabinet Material	Galvanized Steel"	Galvanized Steel"	Galvanized Steel"	Galvanized Steel"
Dimensions (in.):
Length	21.3	29.5	31	36
Width	14.3	14.3	18.3	22
Height	18	18	28.3	30
Net Weight (lbs.)	52	65	116	150
Shipping Weight (lbs.)	57	70	126	160
Accessories:
Chain Hanging Kit	Optional	Optional	Optional	Optional
Air Diverter	Optional	Optional	Optional	Optional
Second Stage Regulator	Optional	Optional	Optional	Optional
Thermostat	Optional	Optional	Optional	Optional
Sediment Trap	Standard	Standard	Standard	Standard
Gas HoM (10R)	Optional	Optional	Optional	Optional
inatalation Ogionec	Optional	Optional	Optional	Optional
indor Mount	Yes	Yes	Yes	Yes
Ouldoor Mount	Yes	Yes	Yes	Yes
CSACertled	Yes	Yes	Yes	Yes
